Description:
Drummed bitumen melting machine is used to decant bitumen out of drums and heating up bitumen.
SINOSUN DT series drummed bitumen melting machine can make full use of hot gas of burner to make bitumen coming out of drums, and use the hot oil heating coils to heat up bitumen indirectly, which prevents bitumen from aging during heating.
Other functions of bitumen melting machine are dehydration and removing residue automatically.
Our DT series drummed bitumen melting machine is popular for its features of energy saving and environment friendly.
Performance:
1. Special enclosed construction which is more environmental friendly.
2. Adopt automatical control system and imported auto-ignite burner.
3. Strong applicability. It is suitable for various types of drums. Even when the drum is out of shape, the machine could still be operated normally.
4. Energy-saving. It makes full use of hot gas (320-450℃) of burner to melt and make bitumen coming out of drums (it is about 150℃ while waste gas was let off to air). The closed-construction saves 50% energy sources compared with the exposed one.
5. Easy to transport, operate and install.
Model
DT4
DT6
DT8
Productivity (t/h)
4
6
8
Asphalt Temp(℃)
120-140
120-140
120-140
Number of Drums per Batch
20
32
44
Thermal Capacity of Oil Heater(kcal/h)
30×104
50×104
60×104
Thermal Oil Temp(℃)
200-240
200-240
200-240
Total Power (kw)
30
38
38
Total Weight (t)
16
22
28
Overall Dimensions (L×W×H) (mm)
8000×1750×2560
9050×2550×2560
12000×2550×2560
